Foldkit 0.158.0

Foldkit 0.158.0 is out. This release focuses on Machine, Foldkit's experimental API for modeling workflows as typed transition tables.

Imagine a checkout where ClickedContinue moves Cart to Shipping, Shipping to Payment, and Payment to Review. A Machine collects those rules in one table so you can read the allowed transitions together, test them, and generate a diagram from the same definition.

Machine has been available for a while. This release makes it easier to use inside an application, and the new Machine guide covers when to reach for it, how to integrate it, and how to keep a larger flow readable. It still ships from foldkit/experimental while the API settles.

A Machine Edge now returns the same shape as update: { model }, with commands when it has work to run.

Previously, to and when took a state builder and a separate Commands callback. In this example, both callbacks build the same order:

Before:

to(
  'Placing',
  ({ state }) => CheckoutState.Placing({ order: orderFromReview(state) }),
  ({ state }) => [PlaceOrder({ order: orderFromReview(state) })],
)

After:

to('Placing', ({ state }) => {
  const nextOrder = orderFromReview(state)

  return {
    model: CheckoutState.Placing({ order: nextOrder }),
    commands: [PlaceOrder({ order: nextOrder })],
  }
})

The handler derives the order once and uses it for both the next state and the Command. The Command still executes through the Runtime after update returns.

This is a breaking change. Wrap existing state returns in { model }, and move any separate Commands callback into the same handler's commands field.

Thank you to @hdoro for suggesting that Machine Edges return Model and Commands together!

A checkout may allow cancellation from Cart, Shipping, Payment, and Review. Repeating that Edge under every state makes it harder to see which transitions actually differ.

Machine.forStates(...).on(...) now lets you declare the cancellation once in the Machine's shared array:

shared: [
  Machine.forStates(['Cart', 'Shipping', 'Payment', 'Review']).on({
    ClickedCancel: to('Cancelled', ({ state }) => ({
      model: CheckoutState.Cancelled({
        isShippingRequired: state.isShippingRequired,
      }),
    })),
  }),
]

The handler's state narrows to the selected variants, so it can read their common fields. A state-local transition overrides the shared default for the same Message. Overlapping shared declarations throw when the Machine is defined.

Shared transitions also appear in the Machine's graph analysis and Mermaid output.

Machine.fold handles the work of reading a Machine state from the enclosing Model, running a transition, writing the next state back, and returning its Commands:

const foldCheckout = Machine.fold({
  machine: checkoutMachine,
  read: (model: Model) => Option.some(model.checkout),
  write: (model, nextCheckout) => evo(model, { checkout: () => nextCheckout }),
})

Call foldCheckout(model, message) from update, or use foldCheckout(message) as a Step in Update.combine. If the Machine exists only in some Model variants, read can return Option.none() elsewhere and the fold leaves the Model unchanged.

Machines can also declare a Schema for read-only context. For example, a checkout guard can consult current inventory held elsewhere in the Model without copying it into every checkout state. Machine.fold reads that context from the enclosing Model for each transition. Direct calls to transition and step must supply it too.

Machine.step now explains why a Message produced no transition:

• OutOfAlphabet: the Message tag appears nowhere in the table.

• NotApplicable: the table knows the Message, but the current state has no Edge for it.

• GuardsFellThrough: every guard declined and there was no fallback.

• ExplicitlyIgnored: evaluation reached the new ignore() fallback.

Use ignore() at the end of a guard list when doing nothing is intentional. Tests and inspectors can distinguish that decision from guards that fell through without a fallback. Static analysis also reports Edges after ignore() as dead transitions.

If you construct or assert an Ignored result, add its required reason field. Exhaustive matches over GuardedEdge, IgnoredReason, and DeadTransitionReason also need to handle the new ignore cases.

• Machine.define accepts nested state unions without throwing at module load.

• Reachability analysis now excludes Edges shadowed by an earlier otherwise, and dead-transition reports list each Edge once.

• Machine.StateTransitions preserves state and Message narrowing when you extract a state's transition entry into a named binding.

• The docs have larger text, more space between sections, Inter for body text, and Paper Mono for code. Search is also available from the landing page.

The Machine guide walks through guards, context, shared transitions, update integration, graph analysis, and pure tests. The state machine example lets you step through a checkout and inspect its transitions as you go.

The full 0.158.0 release notes cover every package and migration detail.

Thanks to everyone building with Foldkit!

Devin
